Docker学习笔记

基本概念

镜像(image)：docker镜像就是一个模板，可以通过这个镜像来创建容器服务。

容器(container)：把容器理解为简易的linux，独立的运行一个或一组应用，通过镜像来创建

仓库：存放镜像的位置，分为公有和私有

安装Docker

环境准备

Linux环境

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
[root@centos7vm ~]# uname -r
3.10.0-1062.el7.x86_64

[root@centos7vm ~]# cat /etc/os-release
NAME="CentOS Linux"
VERSION="7 (Core)"
ID="centos"
ID_LIKE="rhel fedora"
VERSION_ID="7"
PRETTY_NAME="CentOS Linux 7 (Core)"
ANSI_COLOR="0;31"
CPE_NAME="cpe:/o:centos:centos:7"
HOME_URL="https://www.centos.org/"
BUG_REPORT_URL="https://bugs.centos.org/"

CENTOS_MANTISBT_PROJECT="CentOS-7"
CENTOS_MANTISBT_PROJECT_VERSION="7"
REDHAT_SUPPORT_PRODUCT="centos"
REDHAT_SUPPORT_PRODUCT_VERSION="7"

安装

官网帮助文档

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
# 1. 卸载旧版本
sudo yum remove docker \
                  docker-client \
                  docker-client-latest \
                  docker-common \
                  docker-latest \
                  docker-latest-logrotate \
                  docker-logrotate \
                  docker-engine
# 2. 需要的安装包
sudo yum install -y yum-utils
# 3. 设置镜像仓库
sudo yum-config-manager \
    --add-repo \
    https://download.docker.com/linux/centos/docker-ce.repo # 默认是国外的
sudo yum-config-manager \
	--add-repo \
	https://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo
	# 这里用阿里云的

# 4. 安装docker相关的包  docker-ce 社区  ee企业版
sudo yum install -y docker-ce docker-ce-cli containerd.io
# 5. 启动docker
sudo systemctl start docker
# 6. 使用docker version测试是否成功
[root@centos7vm ~]# docker version
Client: Docker Engine - Community
 Version:           19.03.13
 API version:       1.40
 Go version:        go1.13.15
 Git commit:        4484c46d9d
 Built:             Wed Sep 16 17:03:45 2020
 OS/Arch:           linux/amd64
 Experimental:      false

Server: Docker Engine - Community
 Engine:
  Version:          19.03.13
  API version:      1.40 (minimum version 1.12)
  Go version:       go1.13.15
  Git commit:       4484c46d9d
  Built:            Wed Sep 16 17:02:21 2020
  OS/Arch:          linux/amd64
  Experimental:     false
 containerd:
  Version:          1.3.7
  GitCommit:        8fba4e9a7d01810a393d5d25a3621dc101981175
 runc:
  Version:          1.0.0-rc10
  GitCommit:        dc9208a3303feef5b3839f4323d9beb36df0a9dd
 docker-init:
  Version:          0.18.0
  GitCommit:        fec3683
# 7. 使用Hello world测试是否安装成功
docker run hello-world

image-20201107230858385

1
2
3
4
# 8. 查看下载的helloworld镜像
[root@centos7vm ~]# docker images
REPOSITORY          TAG                 IMAGE ID            CREATED             SIZE
hello-world         latest              bf756fb1ae65        10 months ago       13.3kB

阿里云镜像加速

1
2
3
4
5
6
7
8
sudo mkdir -p /etc/docker
sudo tee /etc/docker/daemon.json <<-'EOF'
{
  "registry-mirrors": ["https://l5e8i15v.mirror.aliyuncs.com"]
}
EOF
sudo systemctl daemon-reload
sudo systemctl restart docker

底层原理

Docker是怎么工作的？

Docker是一个Client-server结构的系统，Docker守护进程运行在主机上，通过Socket从客户端访问。

DockerServer接收到Docker-client的指令，就会执行这个命令。

Docker为什么比VM快？

  1. Docker比虚拟机更少的抽象层
  2. Docker利用的是宿主机的内核，vm需要的是Guest os

image-20201107232451728

所以，新建一个容器的时候，Docker不需要像虚拟机一样重新加载一个操作系统，避免引导。虚拟机是加载Guest os，分钟级别，而Docker是利用宿主机的操作系统 ，省略这个过程，秒级。

Docker常用命令

帮助命令

1
2
3
docker version		# 版本信息
docker info			# 显示Docker系统信息，包括镜像和容器的数量
docker 命令 --help    # 帮助命令

官方帮助文档

镜像命令

docker images 查看所有本地的主机上的镜像

1
2
3
4
5
6
7
8
9
10
11
12
13
[root@centos7vm docker]# docker images
REPOSITORY          TAG                 IMAGE ID            CREATED             SIZE
hello-world         latest              bf756fb1ae65        10 months ago       13.3kB

# 解释
REPOSITORY	镜像的仓库源
TAG			镜像的标签
IMAGE ID	镜像的ID
CREATED		镜像的创建时间
SIZE		镜像的大小
# 可选项
-a, --all		# 列出所有镜像
-q, --quiet		# 只显示镜像id

docker search 搜索镜像

1
2
3
4
5
6
[root@centos7vm docker]# docker search mysql
NAME                              DESCRIPTION                                     STARS               OFFICIAL            AUTOMATED
mysql                             MySQL is a widely used, open-source relation…   10134               [OK]

# 可选项，通过收藏来过滤
--filter=stars=3000 #搜索3000以上的

docker pull 下载镜像

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
[root@centos7vm docker]# docker pull mysql
Using default tag: latest # 不写tag 默认是latest
latest: Pulling from library/mysql
bb79b6b2107f: Pull complete # 分层下载，联合文件系统
49e22f6fb9f7: Pull complete
842b1255668c: Pull complete
9f48d1f43000: Pull complete
c693f0615bce: Pull complete
8a621b9dbed2: Pull complete
0807d32aef13: Pull complete
a56aca0feb17: Pull complete
de9d45fd0f07: Pull complete
1d68a49161cc: Pull complete
d16d318b774e: Pull complete
49e112c55976: Pull complete
Digest: sha256:8c17271df53ee3b843d6e16d46cff13f22c9c04d6982eb15a9a47bd5c9ac7e2d # 签名
Status: Downloaded newer image for mysql:latest
docker.io/library/mysql:latest #真实地址


docker pull mysql
docker pull docker.io/library/mysql:latest  # 这两个命令等价

# 指定版本下载
docker pull mysql:5.7

docker rmi 删除镜像

1
2
3
[root@centos7vm docker]# docker rmi -f db2b37ec6181 # 删除指定镜像
[root@centos7vm docker]# docker rmi -f 镜像id 镜像id 镜像id  # 删除多个镜像
[root@centos7vm docker]# docker rmi -f $(docker images -aq)  # 删除全部镜像

容器命令

说明：我们有了镜像才能创建容器，下载一个centos测试学习

1
docker pull centos

新建容器并启动

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
docker run [可选参数] image
# 参数说明
--name="Name"  	容器名字，用来区分容器
-d				后台方式运行
-it				使用交互方式运行，进入容器查看内容
-p				指定容器端口  -p 8080:8080
	-p ip:主机端口:端口
	-p 主机端口:容器  (常用)
	-p 容器端口
	容器端口
-P				随机指定端口
# 测试 启动并进入容器
[root@centos7vm docker]# docker run -it centos /bin/bash
[root@02861391cd3a /]#

# 从容器退回主机

退出容器

1
2
exit # 停止容器并退出
ctrl + p + q  #退出容器不停止

列出所有运行容器

1
2
3
4
5
6
7
8
9
10
11
12
docker ps 命令
	# 列出当前正在运行的容器
-a  # 列出当前正在运行的+历史运行过的容器
-n=? #显示最近创建的容器
-q # 只显示容器的不编号

[root@centos7vm docker]# docker ps
CONTAINER ID        IMAGE               COMMAND             CREATED             STATUS              PORTS               NAMES
[root@centos7vm docker]# docker ps -a
CONTAINER ID        IMAGE               COMMAND             CREATED              STATUS                      PORTS               NAMES
02861391cd3a        centos              "/bin/bash"         About a minute ago   Exited (0) 41 seconds ago                       brave_wright
67d2c31f379c        bf756fb1ae65        "/hello"            48 minutes ago       Exited (0) 48 minutes ago                       exciting_mirzakhani

删除容器

1
2
3
docker rm 容器id # 删除指定容器
docker rm -f $(docker ps -aq) #删除所有容器
docker ps -aq | xargs docker rm #删除所有容器

启动和停止容器的操作

1
2
3
4
docker start 容器id		#启动容器
docker restart  容器id	# 重启容器
docker stop  容器id 		# 停止容器
docker kill  容器id		# 强制停止容器

后台启动容器

1
2
3
4
5
docker run -d centos

# 问题 docker ps 发现容器停止了
# 常见的问题，docker容器后台运行，必须要有一个前台进程，docker发现没有对外提供服务的应用，就会停止
# nginx，容器启动后，发现自己没有提供服务，就会立刻停止，就是没有程序了

查看日志

1
2
3
4
5
6
7
docker logs
# 显示日志
docker logs -tf --tail 10 19d1483e6662
	-tf   # 显示日志
	--tail number  # 要显示日志的跳数
# 自己写一段脚本

查看容器中进程信息

1
2
3
4
5
# 命令 docker top 容器id
[root@centos7vm docker]#  docker top 19d1483e6662
UID                 PID                 PPID                C                   STIME               TTY                 TIME                CMD
root                21885               21867               0                   17:02               ?                   00:00:00            /bin/sh -c while true;do echo 123;sleep 1;done
root                22090               21885               0                   17:04               ?                   00:00:00            /usr/bin/coreutils --coreutils-prog-shebang=sleep /usr/bin/sleep 1

查看镜像元数据

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
[root@centos7vm docker]# docker inspect --help

Usage:  docker inspect [OPTIONS] NAME|ID [NAME|ID...]

Return low-level information on Docker objects

Options:
  -f, --format string   Format the output using the given Go template
  -s, --size            Display total file sizes if the type is container
      --type string     Return JSON for specified type
[root@centos7vm docker]# docker ps
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS              PORTS               NAMES
19d1483e6662        centos              "/bin/sh -c 'while t…"   4 minutes ago       Up 4 minutes                            confident_murdock
[root@centos7vm docker]# docker inspect 19d1483e6662
[
    {
        "Id": "19d1483e66621a38c4e175b4c4615adb3427eaaa07a632f3fa5835ff264a639a",
        "Created": "2020-11-08T09:02:27.513000805Z",
        "Path": "/bin/sh",
        "Args": [
            "-c",
            "while true;do echo 123;sleep 1;done"
        ],
        "State": {
            "Status": "running",
            "Running": true,
            "Paused": false,
            "Restarting": false,
            "OOMKilled": false,
            "Dead": false,
            "Pid": 21885,
            "ExitCode": 0,
            "Error": "",
            "StartedAt": "2020-11-08T09:02:28.217868188Z",
            "FinishedAt": "0001-01-01T00:00:00Z"
        },
        "Image": "sha256:0d120b6ccaa8c5e149176798b3501d4dd1885f961922497cd0abef155c869566",
        "ResolvConfPath": "/var/lib/docker/containers/19d1483e66621a38c4e175b4c4615adb3427eaaa07a632f3fa5835ff264a639a/resolv.conf",
        "HostnamePath": "/var/lib/docker/containers/19d1483e66621a38c4e175b4c4615adb3427eaaa07a632f3fa5835ff264a639a/hostname",
        "HostsPath": "/var/lib/docker/containers/19d1483e66621a38c4e175b4c4615adb3427eaaa07a632f3fa5835ff264a639a/hosts",
        "LogPath": "/var/lib/docker/containers/19d1483e66621a38c4e175b4c4615adb3427eaaa07a632f3fa5835ff264a639a/19d1483e66621a38c4e175b4c4615adb3427eaaa07a632f3fa5835ff264a639a-json.log",
        "Name": "/confident_murdock",
        "RestartCount": 0,
        "Driver": "overlay2",
        "Platform": "linux",
        "MountLabel": "",
        "ProcessLabel": "",
        "AppArmorProfile": "",
        "ExecIDs": null,
        "HostConfig": {
            "Binds": null,
            "ContainerIDFile": "",
            "LogConfig": {
                "Type": "json-file",
                "Config": {}
            },
            "NetworkMode": "default",
            "PortBindings": {},
            "RestartPolicy": {
                "Name": "no",
                "MaximumRetryCount": 0
            },
            "AutoRemove": false,
            "VolumeDriver": "",
            "VolumesFrom": null,
            "CapAdd": null,
            "CapDrop": null,
            "Capabilities": null,
            "Dns": [],
            "DnsOptions": [],
            "DnsSearch": [],
            "ExtraHosts": null,
            "GroupAdd": null,
            "IpcMode": "private",
            "Cgroup": "",
            "Links": null,
            "OomScoreAdj": 0,
            "PidMode": "",
            "Privileged": false,
            "PublishAllPorts": false,
            "ReadonlyRootfs": false,
            "SecurityOpt": null,
            "UTSMode": "",
            "UsernsMode": "",
            "ShmSize": 67108864,
            "Runtime": "runc",
            "ConsoleSize": [
                0,
                0
            ],
            "Isolation": "",
            "CpuShares": 0,
            "Memory": 0,
            "NanoCpus": 0,
            "CgroupParent": "",
            "BlkioWeight": 0,
            "BlkioWeightDevice": [],
            "BlkioDeviceReadBps": null,
            "BlkioDeviceWriteBps": null,
            "BlkioDeviceReadIOps": null,
            "BlkioDeviceWriteIOps": null,
            "CpuPeriod": 0,
            "CpuQuota": 0,
            "CpuRealtimePeriod": 0,
            "CpuRealtimeRuntime": 0,
            "CpusetCpus": "",
            "CpusetMems": "",
            "Devices": [],
            "DeviceCgroupRules": null,
            "DeviceRequests": null,
            "KernelMemory": 0,
            "KernelMemoryTCP": 0,
            "MemoryReservation": 0,
            "MemorySwap": 0,
            "MemorySwappiness": null,
            "OomKillDisable": false,
            "PidsLimit": null,
            "Ulimits": null,
            "CpuCount": 0,
            "CpuPercent": 0,
            "IOMaximumIOps": 0,
            "IOMaximumBandwidth": 0,
            "MaskedPaths": [
                "/proc/asound",
                "/proc/acpi",
                "/proc/kcore",
                "/proc/keys",
                "/proc/latency_stats",
                "/proc/timer_list",
                "/proc/timer_stats",
                "/proc/sched_debug",
                "/proc/scsi",
                "/sys/firmware"
            ],
            "ReadonlyPaths": [
                "/proc/bus",
                "/proc/fs",
                "/proc/irq",
                "/proc/sys",
                "/proc/sysrq-trigger"
            ]
        },
        "GraphDriver": {
            "Data": {
                "LowerDir": "/var/lib/docker/overlay2/86b18b8dd45c45fd5ed8e6d2ed808c689e9061e61c6526c055637d349d4f98dc-init/diff:/var/lib/docker/overlay2/b61e299d2bb31a1fb57bbdf890f6d559b1a92394e98c4b2463c1e0c34ed37341/diff",
                "MergedDir": "/var/lib/docker/overlay2/86b18b8dd45c45fd5ed8e6d2ed808c689e9061e61c6526c055637d349d4f98dc/merged",
                "UpperDir": "/var/lib/docker/overlay2/86b18b8dd45c45fd5ed8e6d2ed808c689e9061e61c6526c055637d349d4f98dc/diff",
                "WorkDir": "/var/lib/docker/overlay2/86b18b8dd45c45fd5ed8e6d2ed808c689e9061e61c6526c055637d349d4f98dc/work"
            },
            "Name": "overlay2"
        },
        "Mounts": [],
        "Config": {
            "Hostname": "19d1483e6662",
            "Domainname": "",
            "User": "",
            "AttachStdin": false,
            "AttachStdout": false,
            "AttachStderr": false,
            "Tty": false,
            "OpenStdin": false,
            "StdinOnce": false,
            "Env": [
                "PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin"
            ],
            "Cmd": [
                "/bin/sh",
                "-c",
                "while true;do echo 123;sleep 1;done"
            ],
            "Image": "centos",
            "Volumes": null,
            "WorkingDir": "",
            "Entrypoint": null,
            "OnBuild": null,
            "Labels": {
                "org.label-schema.build-date": "20200809",
                "org.label-schema.license": "GPLv2",
                "org.label-schema.name": "CentOS Base Image",
                "org.label-schema.schema-version": "1.0",
                "org.label-schema.vendor": "CentOS"
            }
        },
        "NetworkSettings": {
            "Bridge": "",
            "SandboxID": "06d26833c3845620a37f361cda733999dba841c8f80bd14691d7a6275e2f0430",
            "HairpinMode": false,
            "LinkLocalIPv6Address": "",
            "LinkLocalIPv6PrefixLen": 0,
            "Ports": {},
            "SandboxKey": "/var/run/docker/netns/06d26833c384",
            "SecondaryIPAddresses": null,
            "SecondaryIPv6Addresses": null,
            "EndpointID": "990d153ba0bf1db91808560d3f87069dda4a2d98f8d614bf50dcde4e9e95d9a2",
            "Gateway": "172.17.0.1",
            "GlobalIPv6Address": "",
            "GlobalIPv6PrefixLen": 0,
            "IPAddress": "172.17.0.2",
            "IPPrefixLen": 16,
            "IPv6Gateway": "",
            "MacAddress": "02:42:ac:11:00:02",
            "Networks": {
                "bridge": {
                    "IPAMConfig": null,
                    "Links": null,
                    "Aliases": null,
                    "NetworkID": "8c37dffaecb4dec076d5745cb032f23a991ec67976c1e2ae78e837d60075d48c",
                    "EndpointID": "990d153ba0bf1db91808560d3f87069dda4a2d98f8d614bf50dcde4e9e95d9a2",
                    "Gateway": "172.17.0.1",
                    "IPAddress": "172.17.0.2",
                    "IPPrefixLen": 16,
                    "IPv6Gateway": "",
                    "GlobalIPv6Address": "",
                    "GlobalIPv6PrefixLen": 0,
                    "MacAddress": "02:42:ac:11:00:02",
                    "DriverOpts": null
                }
            }
        }
    }
]

进入当前运行的容器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
# 容器通常都是后台运行，需要进入容器修改一些配置

# 命令
# 方式一
docker exec -it 容器id bashshell
[root@centos7vm docker]# docker exec -it 19d1483e6662 /bin/bash
[root@19d1483e6662 /]# ls
bin  dev  etc  home  lib  lib64  lost+found  media  mnt  opt  proc  root  run  sbin  srv  sys  tmp  usr  var
[root@19d1483e6662 /]# ps -ef
UID         PID   PPID  C STIME TTY          TIME CMD
root          1      0  0 09:02 ?        00:00:00 /bin/sh -c while true;do echo 123;sleep 1;done
root        448      0  0 09:09 pts/0    00:00:00 /bin/bash
root        465      1  0 09:09 ?        00:00:00 /usr/bin/coreutils --coreutils-prog-shebang=sleep /usr/bin/sleep 1
root        466    448  3 09:09 pts/0    00:00:00 ps -ef

# 方式二
# 测试
docker attach -it 19d1483e6662
正在执行的代码....

# 区别
# docker exec  # 进入容器后开启一个新的终端，可以在里面操作
# docker attach	# 进入容器正在执行的终端，不会启动新的进程

从容器内拷贝文件到主机上

1
2
3
4
5
6
7
8
9
10
11
12
docker cp 容器ID:容器内路径   目的主机路径

# 进入容器内部
[root@centos7vm ~]# docker ps
CONTAINER ID        IMAGE               COMMAND             CREATED             STATUS              PORTS               NAMES
df42673d50f2        centos              "/bin/bash"         28 seconds ago      Up 25 seconds                           magical_jones
[root@centos7vm ~]# docker attach df42673d50f2
# 新建一个文件测试，将文件copy出来
[root@df42673d50f2 /]# touch test.java
[root@centos7vm ~]# docker cp df42673d50f2:/test.java ./

# copy是一个手动过程，未来使用卷的技术来对路径做映射

练习

安装Nginx

image-20201108173050520

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
# 1. 搜索镜像   建议在Docker Hub上搜索  能够看到详细信息
[root@centos7vm ~]# docker search -f stars=1000 nginx
NAME                  DESCRIPTION                                     STARS               OFFICIAL            AUTOMATED
nginx                 Official build of Nginx.                        13977               [OK]
jwilder/nginx-proxy   Automated Nginx reverse proxy for docker con…   1906                                    [OK]
# 2. 下载镜像
[root@centos7vm ~]# docker pull nginx
Using default tag: latest
latest: Pulling from library/nginx
bb79b6b2107f: Pull complete
5a9f1c0027a7: Pull complete
b5c20b2b484f: Pull complete
166a2418f7e8: Pull complete
1966ea362d23: Pull complete
Digest: sha256:aeade65e99e5d5e7ce162833636f692354c227ff438556e5f3ed0335b7cc2f1b
Status: Downloaded newer image for nginx:latest
docker.io/library/nginx:latest
# 3. 启动容器
-d	# 后台运行
--name # 为容器起名字
-p 	# 暴露端口   宿主机端口：容器内部端口
[root@centos7vm ~]# docker run -d --name nginx01 -p 3344:80 nginx
cb3b7175c1b43ee40bd2f398ed24854eb1a487ee305cec13735603ed5ab8c8e6
[root@centos7vm ~]# docker ps
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS              PORTS                  NAMES
cb3b7175c1b4        nginx               "/docker-entrypoint.…"   6 seconds ago       Up 4 seconds        0.0.0.0:3344->80/tcp   nginx01
# 4. 进入容器
docker exec nginx01 /bin/bash

安装tomcat

1
2
3
4
5
6
7
8
9
10
11
12
13
# 官方的使用
$ docker run -it --rm tomcat:9.0

# 我们之前的启动都是后台，停止了容器后，容器还是可以查到  docker run -it --rm， 一般用来测试，用完即删

# 下载再启动
[root@centos7vm ~]# docker run -d -p 3355:8080 --name tomcat01 tomcat
# 测试访问没有问题

# 进入容器
[root@centos7vm ~]# docker exec -it tomcat01 /bin/bash
# linux命令少、没有webapps   默认是最小的镜像，不必要的都剔除
# 保证最小可运行的环境

部署es+kibana

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
# es占内存多
# es暴露端口多
# es的数据一般需要放置到安全目录 挂载
# --net somenetwork 网络配置
$ docker run -d --name elasticsearch --net somenetwork -p 9200:9200 -p 9300:9300 -e "discovery.type=single-node" elasticsearch:tag

# 启动elasticsearch
docker run -d --name elasticsearch -p 9200:9200 -p 9300:9300 -e "discovery.type=single-node" elasticsearch


# docker stats查看CPU状态
docker stats
# 增加内存的限制  -e参数进行环境修改
docker run -d --name elasticsearch -p 9200:9200 -p 9300:9300 -e "discovery.type=single-node" -e ES_JAVA_OPTS="-Xms64m -Xmx512m" elasticsearch
# 查看状态

image-20201108180804691

1
2
3
4
5
6
7
8
9
10
11
12
13
14
[root@centos7vm ~]# curl localhost:9211
{
  "name" : "UrvHV2Q",
  "cluster_name" : "elasticsearch",
  "cluster_uuid" : "NHWT8qNERMe9UhNZSUSGpw",
  "version" : {
    "number" : "5.6.12",
    "build_hash" : "cfe3d9f",
    "build_date" : "2018-09-10T20:12:43.732Z",
    "build_snapshot" : false,
    "lucene_version" : "6.6.1"
  },
  "tagline" : "You Know, for Search"
}

可视化

  • portainer
  • Rancher(CI/CD再用)

什么是portainer？

Docker图形化界面管理工具，提供一个后台面板

1
[root@centos7vm ~]# docker run -d -p 8088:9000 --restart=always -v /var/run/docker.sock:/var/run/docker.sock --privileged=true portainer/portainer-ce

commit 镜像

1
2
3
4
docker commit 提交容器成为一个新的副本
# 命令和git类似
docker commit -m="提交的描述信息" -a="作者" 容器ID  目标镜像名：[TAG]

练习

1
2
3
4
5
6
7
8
9
10
11
12
13
# 启动一个默认的tomcat
# 默认的tomcat没有webapps应用，
# 自己将webapps.dist内容拷贝进去
# 通过commit提交了一个新的镜像
docker commit -a="halfcoke" -m="add webapps app" 容器ID tomcat01:1.1

[root@centos7vm ~]# docker commit -a="halfcoke" -m="add webapps app" d59f955ed1ac tomcat_test:1.0
sha256:8119e221b3f258d762ca461759af00417f2ea2e3d6eccf0b7dee850c5cb7ee53
[root@centos7vm ~]# docker images
REPOSITORY               TAG                 IMAGE ID            CREATED             SIZE
tomcat_test              1.0                 8119e221b3f2        7 seconds ago       653MB
tomcat                   9.0                 dab3cf97dd54        39 hours ago        648MB
tomcat                   latest              dab3cf97dd54        39 hours ago        648MB

容器数据卷

什么是数据卷

image-20201108195121399

容器内的目录映射到外部目录，为了容器的持久化和同步操作，容器间数据能够共享

使用数据卷

方式一：使用命令挂载 -v

1
2
3
4
5
6
docker run -it -v 主机目录：容器内目录 -p 主机端口：容器端口

docker run -it -v /root/test:/home centos /bin/bash

# 通过inspect 查看容器信息
docker inspect 容器id

image-20201108195708778

其中source是主机内的地址，Destination是容器内的地址

1
# 测试

image-20201108200240055

之后修改直接在本地修改

练习 安装mysql

1
2
3
4
5
6
7
8
9
10
11
12
13
14
# 下载镜像
[root@centos7vm ~]# docker pull mysql:5.7

# 官方测试
docker run --name some-mysql -e MYSQL_ROOT_PASSWORD=my-secret-pw -d mysql:tag
# 运行容器，需要数据挂载
-d 后台运行
-e 环境配置
--name 名字
-v 卷挂载
-p 端口映射
[root@centos7vm ~]# docker run -d -p 3310:3306 -v /root/mysql/conf:/etc/mysql/conf.d -v /root/mysql/data:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=123 --name mysql01 mysql:5.7
# 启动成功后，链接测试
# 容器删除后，数据也不会丢失

具名挂载和匿名挂载

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
# 匿名挂载
-v 容器内路径
-P 随机指定端口
docker run -d -P --name nginx01 -v /etc/nginx nginx

# 查看当前挂载的卷
docker volume --help
[root@centos7vm ~]# docker volume --help

Usage:	docker volume COMMAND

Manage volumes

Commands:
  create      Create a volume
  inspect     Display detailed information on one or more volumes
  ls          List volumes
  prune       Remove all unused local volumes
  rm          Remove one or more volumes

Run 'docker volume COMMAND --help' for more information on a command.
# 查看所有的卷的情况
# 这里发现volume name都是加密后的，没有指定容器外的路径，就是匿名挂载
[root@centos7vm ~]# docker volume ls
DRIVER              VOLUME NAME
local               4ec45c6cdf92869673d25a42192fb0fe4d272e90343a4ca55650364e4ffda7fc
local               5b4a7949963490b29a916aec8dbac7e552bbf915fb3863da2902475d2c9483c2
local               5dfa3b399cff8cc630c709e738ace5feacd91085f0e2aad61f7cc7353abf3fa1
local               d5cdb69a6cc404ebb990956c8c8132e589010d1176e3a0a4bf3624992f74c236
local               f258608b52225ead6f764860b476f188cd1794e1533e667953fb6b98855b09ee
local               fece1a11094a2f65d572ea20c0e2561efc4a738a9a84667f5f6d5d9d0bf9a6a8
# 可以直接以  名字:容器内路径 的方式指定数据卷挂载，这就是具名挂载
# docker -v 卷名：容器内路径
[root@centos7vm ~]# docker run -d -P --name nginx02 -v juming:/etc/nginx nginx
7dba2abd87dfd70ea89c957b03dd797a3b9a8ae9597ed478dc22155c4676eb05
[root@centos7vm ~]# docker volume ls
DRIVER              VOLUME NAME
local               4ec45c6cdf92869673d25a42192fb0fe4d272e90343a4ca55650364e4ffda7fc
local               5b4a7949963490b29a916aec8dbac7e552bbf915fb3863da2902475d2c9483c2
local               5dfa3b399cff8cc630c709e738ace5feacd91085f0e2aad61f7cc7353abf3fa1
local               d5cdb69a6cc404ebb990956c8c8132e589010d1176e3a0a4bf3624992f74c236
local               f258608b52225ead6f764860b476f188cd1794e1533e667953fb6b98855b09ee
local               fece1a11094a2f65d572ea20c0e2561efc4a738a9a84667f5f6d5d9d0bf9a6a8
local               juming

# 通过docker volume inspect 来查看卷名的具体位置
# 在没有指定目录的情况下，都是在/var/lib/docker/volumes/xxxx/_data
# 我们通过具名挂载可以方便的找一个卷，大多数情况都是具名挂载
[root@centos7vm ~]# docker volume inspect juming
[
    {
        "CreatedAt": "2020-11-08T20:25:02+08:00",
        "Driver": "local",
        "Labels": null,
        "Mountpoint": "/var/lib/docker/volumes/juming/_data",
        "Name": "juming",
        "Options": null,
        "Scope": "local"
    }
]
-v 容器内路径  # 匿名挂载
-v 卷名：容器内路径 # 具名挂载
-v /宿主机路径：容器路径  # 指定路径挂载

拓展

1
2
3
4
5
6
7
8
# 通过 -v 容器内路径  ro rw 改变读写权限

# 一旦设置了容器权限，容器对我们挂载出来的内容就有限定了
[root@centos7vm ~]# docker run -d -P --name nginx02 -v juming:/etc/nginx:ro nginx
[root@centos7vm ~]# docker run -d -P --name nginx02 -v juming:/etc/nginx:rw nginx

# ro只能从外部改变，只能从宿主机修改
# rw则可读可写

初识DockerFile

方式二：使用DockerFile挂载

通过dokerFile这个脚本可以生成镜像，每个命令都是一层

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
# vim dockerfile01内容
FROM centos

VOLUME ["volume01","volume02"]

CMD echo "----------end------------"
CMD /bin/bash
# 使用如下命令生成镜像
-f 指定从那个文件生成
-t 镜像名
. 位置
[root@centos7vm docker-test-volume]# docker build -f dockerfile1 -t test_os/centos:1.0 .
Sending build context to Docker daemon  2.048kB
Step 1/4 : FROM centos
 ---> 0d120b6ccaa8
Step 2/4 : VOLUME ["volume01","volume02"]
 ---> Running in 6e98aba39de7
Removing intermediate container 6e98aba39de7
 ---> e2b73d377118
Step 3/4 : CMD echo "----------end------------"
 ---> Running in b36b63a3e0e8
Removing intermediate container b36b63a3e0e8
 ---> f5f1b57f30fa
Step 4/4 : CMD /bin/bash
 ---> Running in f5ac620b0aac
Removing intermediate container f5ac620b0aac
 ---> 22cd294f67ad
Successfully built 22cd294f67ad
Successfully tagged test_os/centos:1.0
# 执行自己的镜像
[root@centos7vm docker-test-volume]# docker run -it 22cd294f67ad /bin/bash
[root@08b42c895f34 /]# ls
bin  dev  etc  home  lib  lib64  lost+found  media  mnt  opt  proc  root  run  sbin  srv  sys  tmp  usr  var  volume01	volume02
# 最后面两个文件夹就是自动挂载的数据卷目录

最后两个卷一定与外部有同步的。

没有写名字，这是匿名挂载

image-20201108210619365

查看容器属性，确定是匿名挂载

image-20201108210750028

这种使用方式非常多，如果构建镜像的时候没有挂载，就要手动挂载 -v 卷名:容器内路径。

数据卷容器

两个mysql之间同步数据

image-20201108211127849

1
# 启动容器，通过自己写的镜像启动

image-20201108211313942

1
2
3
4
5
# 再新建一个容器，从docker01中继承数据卷
[root@centos7vm ~]# docker run -it --name docker02 --volumes-from docker01 test_os/centos:1.0
同一个目录数据可以同步

这里面docker01就叫做数据卷容器

多个mysql数据共享

1
[root@centos7vm ~]# docker run -d -p 3310:3306 --volumes-from mysql01 -e MYSQL_ROOT_PASSWORD=123 --name mysql01 mysql:5.7

DockerFile

基本知识

DockerFile是用来构建Docker镜像的文件，是一种命令参数脚本

构建步骤：

  1. 编写一个dockerfile文件
  2. docker build构建成为一个镜像
  3. docker run 运行镜像
  4. docker push 发布镜像(Docker Hub、阿里云镜像仓库)

dockerfile构建过程

基础知识：

  1. 保留关键字(指令)都必须是大写字母
  2. 指令顺序执行
  3. # 表示注释
  4. 每一个指令都是一个镜像层

DockerFile是面向开发的，以后发布项目，做镜像，就需要编写dockerfile文件。

DockerFile： 构建文件，定义了一切步骤，源代码

DockerImages：通过DockerFile构建生成的镜像，最终发布和运行的产品

Docker容器：容器就是镜像运行起来提供服务的

DockerFile命令

1
2
3
4
5
6
7
8
9
10
11
12
13
FROM 		# 基础镜像，一切从这里开始构建
MAINTAINER	# 镜像是谁写的，姓名+邮箱
RUN			# 镜像构建的时候需要运行的命令
ADD			# 步骤：tomcat镜像，这个tomcat压缩包，添加内容
WORKDIR		# 镜像的工作目录   进入镜像时的目录
VOLUME		# 挂载的目录位置
EXPOSE		# 暴露端口配置
CMD			# 指定容器启动的时候要运行的命令，CMD只有最后一个会生效，而且可被替代
ENTRYPOINT   # 容器启动的时候要运行的命令，可以追加命令
# CMD 与ENTRYPOINT 区别，比如说   ls -l   如果是使用CMD 写ls -a  则执行docker run 会替换掉ls -l   如果是ENTRYPOINT则会变成 ls -a  ls -l 下面详细介绍
ONBUILD 	# 当构建一个被继承DockerFile的时候，就会歘ONBUILD执行，触发指令
COPY 		#  类似ADD,将我们的文件拷贝到镜像中
ENV 		# 构建的时候，设置的环境变量

这里放的图片比较多，更全面的写展示各种命令

image-20201108213930017

image-20201108213418167

image-20201108213512266

image-20201108213536145

实战测试

Docker Hub中绝大多数镜像都是从基础镜像过来的FROM scratch，然后配置需要的软件和环境

image-20201108214918038

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
# 创建自己的centos
# 1. 编写dockerfile文件
[root@centos7vm dockerfile]# cat mycentos.dockerfile
FROM centos
MAINTAINER halfcoke<halfcoke@163.com>

ENV MYPATH /usr/local
WORKDIR $MYPATH

RUN yum -y install vim
RUN yum -y install net-tools

EXPOSE 80

CMD echo $MYPATH
CMD ECHO "------END-----"
CMD /bin/bash
# 2. 通过文件构建镜像
docker build -f mycentos.dockerfile -t mycentos:0.1 .
# 3. 测试运行一下

CMD 和 ENTRYPOINT区别

CMD 只有最后一个CMD会生效

测试cmd

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
# dockerfile文件内容
FROM centos
CMD ["ls","-a"]
# 构建镜像
docker build -f file -t cmdtest .
# 运行结果
[root@centos7vm dockerfile]# docker run cmdtest
.
..
.dockerenv
bin
dev
etc
home
lib
lib64
lost+found
.........
# 想追加一个命令 -l
[root@centos7vm dockerfile]# docker run cmdtest -l
docker: Error response from daemon: OCI runtime create failed: container_linux.go:349: starting container process caused "exec: \"-l\": executable file not found in $PATH": unknown.
ERRO[0000] error waiting for container: context canceled

测试entrypoint

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
# dockerfile文件内容
FROM centos
ENTRYPOINT ["ls","-a"]
# 构建镜像
docker build -f file -t cmdtest .
# 运行结果

[root@centos7vm dockerfile]# docker run entrytest
.
..
.dockerenv
bin
dev
etc
home
lib
lib64
lost+found
media
...............
# 想追加一个命令 -l
[root@centos7vm dockerfile]# docker run entrytest -l
total 0
drwxr-xr-x   1 root root   6 Nov  8 14:08 .
drwxr-xr-x   1 root root   6 Nov  8 14:08 ..
-rwxr-xr-x   1 root root   0 Nov  8 14:08 .dockerenv
lrwxrwxrwx   1 root root   7 May 11  2019 bin -> usr/bin
drwxr-xr-x   5 root root 340 Nov  8 14:08 dev
drwxr-xr-x   1 root root  66 Nov  8 14:08 etc
drwxr-xr-x   2 root root   6 May 11  2019 home
lrwxrwxrwx   1 root root   7 May 11  2019 lib -> usr/lib
lrwxrwxrwx   1 root root   9 May 11  2019 lib64 -> usr/lib64
drwx------   2 root root   6 Aug  9 21:40 lost+found
drwxr-xr-x   2 root root   6 May 11  2019 media
drwxr-xr-x   2 root root   6 May 11  2019 mnt
drwxr-xr-x   2 root root   6 May 11  2019 opt
dr-xr-xr-x 301 root root   0 Nov  8 14:08 proc
dr-xr-x---   2 root root 162 Aug  9 21:40 root
drwxr-xr-x  11 root root 163 Aug  9 21:40 run
lrwxrwxrwx   1 root root   8 May 11  2019 sbin -> usr/sbin
drwxr-xr-x   2 root root   6 May 11  2019 srv
dr-xr-xr-x  13 root root   0 Nov  8 13:12 sys
drwxrwxrwt   7 root root 145 Aug  9 21:40 tmp
drwxr-xr-x  12 root root 144 Aug  9 21:40 usr
drwxr-xr-x  20 root root 262 Aug  9 21:40 var

练习：TomCat镜像

  1. 准备压缩文件

    image-20201109103657554

  2. 编写Dockerfile文件 官方命名Dockerfile，build就会自动寻找这个文件，不需要-f指定

    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    16
    17
    18
    19
    20
    21
    22
    23
    FROM centos
    MAINTAINER halcoke<halfcoke@163.com>

    COPY readme.txt /usr/local/readme.txt

    ADD jdk-8u271-linux-x64.tar.gz /usr/local/
    ADD apache-tomcat-9.0.39.tar.gz /usr/local/

    RUN yum -y install vim

    ENV MYPATH /usr/local
    WORKDIR $MYPATH

    ENV JAVA_HOME /usr/local/jdk1.8.0_271
    ENV CLASSPATH $JAVA_HOME/lib/dt.jar:$JAVA_HOME/lib/tools.jar
    ENV CATALINA_HOME /usr/local/apache-tomcat-9.0.39
    ENV CATALINA_BASH /usr/local/apache-tomcat-9.0.39
    ENV PATH $PATH:$JAVA_HOME/bin:$CATALINA_HOME/lib:$CATALINA_HOME/bin

    EXPOSE 8080

    CMD /usr/local/apache-tomcat-9.0.39/bin/startup.sh && tail -F /usr/localapache-tomcat-9.0.39/bin/logs/catalina.out

  3. 构建镜像

    1
    docker build -t diytomcat .

  4. 启动镜像

  5. 访问测试

  6. 发布项目

    1
    2
    3
    4
    5
    6
    7
    <?xml version="1.0" encoding="UTF-8"?>
    <web-app version="2.4"
        xmlns="http://java.sun.com/xml/ns/j2ee"
        xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:schemaLocation="http://java.sun.com/xml/ns/j2ee
            http://java.sun.com/xml/ns/j2ee/web-app_2_4.xsd">
    </web-app>
    1
    2
    3
    4
    5
    6
    7
    8
    9
    10
    11
    12
    13
    14
    15
    <%@ page language="java" contentType="text/html; charset=UTF-8"
        pageEncoding="UTF-8"%>
    <!DOCTYPE html>
    <html>
    <head>
    <meta charset="utf-8">
    <title>菜鸟教程(runoob.com)</title>
    </head>
    <body>
    Hello World!<br/>
    <%
    out.println("你的 IP 地址 " + request.getRemoteAddr());
    %>
    </body>
    </html>

    发布镜像

    发布到阿里云

    参考阿里云官方文档

    小结

    image-20201109135918607

Docker网络

理解Docker0

docker生成的网卡

image-20201109140804266

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
# docker 是如何处理网络链接的

# 查看容器内部的ip地址  ip addr， 发现容器启动的时候会得到一个eth0@if97ip地址
[root@centos7vm ~]# docker run -d -P --name tomcat01 tomcat
Unable to find image 'tomcat:latest' locally
latest: Pulling from library/tomcat
e4c3d3e4f7b0: Pull complete
101c41d0463b: Pull complete
8275efcd805f: Pull complete
751620502a7a: Pull complete
a59da3a7d0e7: Pull complete
9c0f1dffe039: Pull complete
474314d81831: Pull complete
90ee5d998c5c: Pull complete
a79c7e2a85e1: Pull complete
1e48dd1bb576: Pull complete
Digest: sha256:ad82afe54f2aa67167e873162578a751aed3173e42250a9ed68f306aa4b83025
Status: Downloaded newer image for tomcat:latest
04c9ac8b93a7efd8c19b0932bcfe5803be94d059fb6f365dd47d2ee63e935fe8
[root@centos7vm ~]# docker exec -it 04c9a /bin/bash
root@04c9ac8b93a7:/usr/local/tomcat# ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
96: eth0@if97: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
    link/ether 02:42:ac:11:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0
    inet 172.17.0.2/16 brd 172.17.255.255 scope global eth0
       valid_lft forever preferred_lft forever
root@04c9ac8b93a7:/usr/local/tomcat#

# linux能够ping通容器内部

原理

  1. 每启动一个docker容器，docker就会给docker容器分配一个ip，我们只要安装了docker，就会有一个docker0

  2. 启动一个容器后，会多出一对网卡，容器内一个，主机上一个

    image-20201109143414467

我们先这个容器网卡，都是一对一对的

evth-pair就是一对虚拟设备接口，他们都是成对出现的，

evth-pair充当一个桥梁，链接各种虚拟网络设备

  1. 两个容器之间也能够ping通
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
# 使用tcpdump 抓包
root@60f31d3cc794:/usr/local/tomcat# tcpdump -i eth0
tcpdump: verbose output suppressed, use -v or -vv for full protocol decode listening on eth0, link-type EN10MB (Ethernet), capture size 262144 bytes
06:51:02.491361 ARP, Request who-has 172.17.0.3 tell 60f31d3cc794, length 28
06:51:02.491396 ARP, Reply 172.17.0.3 is-at 02:42:ac:11:00:03 (oui Unknown), length 28
06:51:02.491398 IP 60f31d3cc794 > 172.17.0.3: ICMP echo request, id 371, seq 1, length 64
06:51:02.491420 IP 172.17.0.3 > 60f31d3cc794: ICMP echo reply, id 371, seq 1, length 64
06:51:02.491718 IP 60f31d3cc794.47353 > 192.168.3.1.domain: 56068+ PTR? 3.0.17.172.in-addr.arpa. (41)
06:51:02.502944 IP 192.168.3.1.domain > 60f31d3cc794.47353: 56068 NXDomain* 0/1/0 (95)
06:51:02.503226 IP 60f31d3cc794.52337 > 192.168.3.1.domain: 16962+ PTR? 1.3.168.192.in-addr.arpa. (42)
06:51:02.504061 IP 192.168.3.1.domain > 60f31d3cc794.52337: 16962 NXDomain- 0/0/0 (42)
06:51:03.494530 IP 60f31d3cc794 > 172.17.0.3: ICMP echo request, id 371, seq 2, length 64
06:51:03.494575 IP 172.17.0.3 > 60f31d3cc794: ICMP echo reply, id 371, seq 2, length 64
06:51:07.501141 ARP, Request who-has 172.17.0.1 tell 60f31d3cc794, length 28
06:51:07.501159 ARP, Request who-has 60f31d3cc794 tell 172.17.0.3, length 28
06:51:07.501165 ARP, Reply 60f31d3cc794 is-at 02:42:ac:11:00:04 (oui Unknown), length 28
06:51:07.501246 ARP, Reply 172.17.0.1 is-at 02:42:65:8d:e1:2b (oui Unknown), length 28
06:51:07.501342 IP 60f31d3cc794.56205 > 192.168.3.1.domain: 41516+ PTR? 1.0.17.172.in-addr.arpa. (41)
06:51:07.507059 IP 192.168.3.1.domain > 60f31d3cc794.56205: 41516 NXDomain* 0/1/0 (95)
06:51:12.522774 ARP, Request who-has 60f31d3cc794 tell 172.17.0.1, length 28
06:51:12.522783 ARP, Reply 60f31d3cc794 is-at 02:42:ac:11:00:04 (oui Unknown), length 28

evth-pair有点类似于一个虚拟交换机，为每个虚拟设备建立一对端口，虚拟设备上一个，宿主机上一个，相当于用网线链接起来。参考链接

容器之间不通过ip可以互相ping通

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
# 直接ping无法ping通
[root@centos7vm ~]# docker exec tomcat01 ping tomcat02
ping: tomcat02: Name or service not known
# 如何解决？
# 通过--link的方式可以连接
[root@centos7vm ~]# docker run -d -P --name tomcat03 --link tomcat02 tomcat
adde4bc5e9fb8e398bbaba77f889819d623df12190f42a4c9eaa93e910ad2bf4
[root@centos7vm ~]# docker ps
CONTAINER ID        IMAGE               COMMAND             CREATED             STATUS              PORTS                     NAMES
adde4bc5e9fb        tomcat              "catalina.sh run"   4 seconds ago       Up 3 seconds        0.0.0.0:32781->8080/tcp   tomcat03
f7fa8f2e44a8        tomcat              "catalina.sh run"   5 hours ago         Up 5 hours          0.0.0.0:32778->8080/tcp   tomcat02
04c9ac8b93a7        tomcat              "catalina.sh run"   5 hours ago         Up 5 hours          0.0.0.0:32777->8080/tcp   tomcat01
[root@centos7vm ~]# docker exec -it tomcat03 ping tomcat02
PING tomcat02 (172.17.0.3) 56(84) bytes of data.
64 bytes from tomcat02 (172.17.0.3): icmp_seq=1 ttl=64 time=0.251 ms
64 bytes from tomcat02 (172.17.0.3): icmp_seq=2 ttl=64 time=0.080 ms
64 bytes from tomcat02 (172.17.0.3): icmp_seq=3 ttl=64 time=0.097 ms
^C
--- tomcat02 ping statistics ---
3 packets transmitted, 3 received, 0% packet loss, time 6ms
rtt min/avg/max/mdev = 0.080/0.142/0.251/0.078 ms
# 反向无法连通
[root@centos7vm ~]# docker exec -it tomcat02 ping tomcat03
ping: tomcat03: Name or service not known
# --link 是在host文件中进行了配置
[root@centos7vm ~]# docker exec tomcat03 cat /etc/hosts
127.0.0.1	localhost
::1	localhost ip6-localhost ip6-loopback
fe00::0	ip6-localnet
ff00::0	ip6-mcastprefix
ff02::1	ip6-allnodes
ff02::2	ip6-allrouters
172.17.0.3	tomcat02 f7fa8f2e44a8
172.17.0.4	adde4bc5e9fb

现在不建议使用–link

docker0问题，不支持容器名链接访问

自定义网络

1
2
3
4
5
6
7
# 查看所有的网络模式
[root@centos7vm ~]# docker network ls
NETWORK ID          NAME                DRIVER              SCOPE
8c37dffaecb4        bridge              bridge              local
35c2a571afd2        host                host                local
b9de4a74c582        none                null                local

网络模式

bridge： 桥接

none：不配置网络

host：和宿主机共享网络

container：容器内网络连通

测试

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
# 是默认增加了--net bridge， 这个就是docker0
[root@centos7vm ~]# docker run -d -P --name tomcat01  tomcat
[root@centos7vm ~]# docker run -d -P --name tomcat01 --net bridge tomcat
# docker0特点，默认，域名不能访问

# 自定义网络
# --driver bridge
# --subnet 192.168.0.0/16
# --gateway 192.168.0.1
[root@centos7vm ~]# docker network create --driver bridge --subnet 192.168.0.0/16 --gateway 192.168.0.1 mynet
8df9a7ad718555216a856cf0c5fa4cf02788f4c840a2d832453a4ab3d3ef3ef6
[root@centos7vm ~]# docker network ls
NETWORK ID          NAME                DRIVER              SCOPE
8c37dffaecb4        bridge              bridge              local
35c2a571afd2        host                host                local
8df9a7ad7185        mynet               bridge              local
b9de4a74c582        none                null                local

image-20201109192308737

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
# 添加两个容器
[root@centos7vm ~]# docker run -d -P --name tomcat01 --net mynet tomcat
54c6db4b62e6ea50dbbffb7559a08f93ff62d3944e10ffa6a32dbec56dc70a22
[root@centos7vm ~]# docker run -d -P --name tomcat02 --net mynet tomcat
80b3e7d6343eca724f0c99c43dfeb0df985163dea8b207046bf375b724a25f6e
[root@centos7vm ~]# docker network inspect mynet
[
    {
        "Name": "mynet",
        "Id": "8df9a7ad718555216a856cf0c5fa4cf02788f4c840a2d832453a4ab3d3ef3ef6",
        "Created": "2020-11-09T19:21:57.212203173+08:00",
        "Scope": "local",
        "Driver": "bridge",
        "EnableIPv6": false,
        "IPAM": {
            "Driver": "default",
            "Options": {},
            "Config": [
                {
                    "Subnet": "192.168.0.0/16",
                    "Gateway": "192.168.0.1"
                }
            ]
        },
        "Internal": false,
        "Attachable": false,
        "Ingress": false,
        "ConfigFrom": {
            "Network": ""
        },
        "ConfigOnly": false,
        "Containers": {
            "54c6db4b62e6ea50dbbffb7559a08f93ff62d3944e10ffa6a32dbec56dc70a22": {
                "Name": "tomcat01",
                "EndpointID": "967a2066e520708347d6b4f7ce52d3eb0d6284684808a6f7222f96f5461dc424",
                "MacAddress": "02:42:c0:a8:00:02",
                "IPv4Address": "192.168.0.2/16",
                "IPv6Address": ""
            },
            "80b3e7d6343eca724f0c99c43dfeb0df985163dea8b207046bf375b724a25f6e": {
                "Name": "tomcat02",
                "EndpointID": "758970ddbc8affa25a1de8a36ce9e013863dc1769694081713affd587cfdf81e",
                "MacAddress": "02:42:c0:a8:00:03",
                "IPv4Address": "192.168.0.3/16",
                "IPv6Address": ""
            }
        },
        "Options": {},
        "Labels": {}
    }
]
# 现在不需要使用--link，也能ping名字了
[root@centos7vm ~]# docker exec tomcat01 ping 192.168.0.3
PING 192.168.0.3 (192.168.0.3) 56(84) bytes of data.
64 bytes from 192.168.0.3: icmp_seq=1 ttl=64 time=0.067 ms
64 bytes from 192.168.0.3: icmp_seq=2 ttl=64 time=0.055 ms
^C
[root@centos7vm ~]# docker exec tomcat01 ping tomcat02
PING tomcat02 (192.168.0.3) 56(84) bytes of data.
64 bytes from tomcat02.mynet (192.168.0.3): icmp_seq=1 ttl=64 time=0.039 ms
64 bytes from tomcat02.mynet (192.168.0.3): icmp_seq=2 ttl=64 time=0.073 ms

我们自定义网络都已经帮我们维护好了对应的关系，推荐使用。

好处：

不同集群使用不同网络，这样能保证网络健康

网络连通

image-20201109192920354

image-20201109192945986

测试打通

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
[root@centos7vm ~]# docker network connect mynet tomcat03
[root@centos7vm ~]# docker network inspect mynet
[
    {
        "Name": "mynet",
        "Id": "8df9a7ad718555216a856cf0c5fa4cf02788f4c840a2d832453a4ab3d3ef3ef6",
        "Created": "2020-11-09T19:21:57.212203173+08:00",
        "Scope": "local",
        "Driver": "bridge",
        "EnableIPv6": false,
        "IPAM": {
            "Driver": "default",
            "Options": {},
            "Config": [
                {
                    "Subnet": "192.168.0.0/16",
                    "Gateway": "192.168.0.1"
                }
            ]
        },
        "Internal": false,
        "Attachable": false,
        "Ingress": false,
        "ConfigFrom": {
            "Network": ""
        },
        "ConfigOnly": false,
        "Containers": {
            "4fb292c8352c281860cb89dd8be171bdc4872f5bca008dc3924256fc6ac7a32a": {
                "Name": "tomcat03",
                "EndpointID": "bcc695da7144029eb0fc674249d3286fb8cc2bba863ef5e1c1197f579e9e6d76",
                "MacAddress": "02:42:c0:a8:00:04",
                "IPv4Address": "192.168.0.4/16",
                "IPv6Address": ""
            },
            "54c6db4b62e6ea50dbbffb7559a08f93ff62d3944e10ffa6a32dbec56dc70a22": {
                "Name": "tomcat01",
                "EndpointID": "967a2066e520708347d6b4f7ce52d3eb0d6284684808a6f7222f96f5461dc424",
                "MacAddress": "02:42:c0:a8:00:02",
                "IPv4Address": "192.168.0.2/16",
                "IPv6Address": ""
            },
            "80b3e7d6343eca724f0c99c43dfeb0df985163dea8b207046bf375b724a25f6e": {
                "Name": "tomcat02",
                "EndpointID": "758970ddbc8affa25a1de8a36ce9e013863dc1769694081713affd587cfdf81e",
                "MacAddress": "02:42:c0:a8:00:03",
                "IPv4Address": "192.168.0.3/16",
                "IPv6Address": ""
            }
        },
        "Options": {},
        "Labels": {}
    }
]
[root@centos7vm ~]# docker exec tomcat03 ip a
1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN group default qlen 1000
    link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00
    inet 127.0.0.1/8 scope host lo
       valid_lft forever preferred_lft forever
111: eth0@if112: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
    link/ether 02:42:ac:11:00:02 brd ff:ff:ff:ff:ff:ff link-netnsid 0
    inet 172.17.0.2/16 brd 172.17.255.255 scope global eth0
       valid_lft forever preferred_lft forever
113: eth1@if114: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc noqueue state UP group default
    link/ether 02:42:c0:a8:00:04 brd ff:ff:ff:ff:ff:ff link-netnsid 0
    inet 192.168.0.4/16 brd 192.168.255.255 scope global eth1
       valid_lft forever preferred_lft forever
[root@centos7vm ~]# docker exec tomcat03 ping tomcat01
PING tomcat01 (192.168.0.2) 56(84) bytes of data.
64 bytes from tomcat01.mynet (192.168.0.2): icmp_seq=1 ttl=64 time=0.108 ms
64 bytes from tomcat01.mynet (192.168.0.2): icmp_seq=2 ttl=64 time=0.048 ms
^C
[root@centos7vm ~]# docker exec tomcat03 ping tomcat02
PING tomcat02 (192.168.0.3) 56(84) bytes of data.
64 bytes from tomcat02.mynet (192.168.0.3): icmp_seq=1 ttl=64 time=0.057 ms
64 bytes from tomcat02.mynet (192.168.0.3): icmp_seq=2 ttl=64 time=0.063 ms

结论，假设跨网络操作，就需要这么操作。

Redis集群

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
# 创建redis配置文件
#!/bin/bash

for port in $(seq 1 6);
do
mkdir -p /mydata/redis/node-${port}/conf
touch /mydata/redis/node-${port}/conf/redis.conf
cat << EOF > /mydata/redis/node-${port}/conf/redis.conf
port 6379
bind 0.0.0.0
cluster-enabled yes
cluster-config-file nodes.conf
cluster-node-timeout 5000
cluster-announce-ip 172.38.0.1${port}
cluster-announce-port 6379
cluster-announce-bus-port 16379
appendonly yes
EOF
done
# 运行容器

#!/bin/bash

for n in $(seq 1 6);
do
docker run -p 637${n}:6379 -p 1637${n}:16379 --name redis-${n} \
-v /mydata/redis/node-${n}/data:/data \
-v /mydata/redis/node-${n}/conf/redis.conf:/etc/redis/redis.conf \
-d --net redis --ip 172.38.0.1${n} redis:5.0.9-alpine3.11 redis-server /etc/redis/redis.conf
done

# 创建集群
/data # redis-cli --cluster create 172.38.0.11:6379 172.38.0.12:6379 172.38.0.13:6379 172.38.0.14:6379 172.38.0.15:6379 172.38.0.16:6379 --cluster-replicas 1

Docker Compose

介绍

定义运行多个容器

YAML file配置文件

single command 命令？

使用compose三个步骤

官方说明：

Using Compose is basically a three-step process:

  1. Define your app’s environment with a Dockerfile so it can be reproduced anywhere.
  2. Define the services that make up your app in docker-compose.yml so they can be run together in an isolated environment.
  3. Run docker-compose up and Compose starts and runs your entire app.

dockerfile 保证我们的项目在任何地方都可以运行

docker-compose.yaml怎么写

使用docker-compose up命令启动compose

其他介绍

compose 是docker官方的开源项目，需要安装。

docker-compose.yml文件格式：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
version: "3.8"
services:
  web:
    build: .
    ports:
      - "5000:5000"
    volumes:
      - .:/code
      - logvolume01:/var/log
    links:
      - redis
  redis:
    image: redis
volumes:
  logvolume01: {}

Compose：重要的概念

  • 服务service：容器，应用
  • 项目project。一组关联的容器。

安装

官方链接

1
2
3
sudo curl -L "https://github.com/docker/compose/releases/download/1.27.4/docker-compose-$(uname -s)-$(uname -m)" -o /usr/local/bin/docker-compose
sudo chmod +x /usr/local/bin/docker-compose
docker-compose --version

练习

官方链接

yaml规则

docker-compose.yml核心

1
2
3
4
5
6
7
8
9
10
11
12
13
# 3层
version: '' # 版本  根据docker版本来
services: # 服务
  服务1: web
    # 服务配置
    build: .
    images: ....
  服务2: redis
  ....
# 其他配置  网络/卷/全局规则
volumes:
networks:
configs:

Docker Swarm

创建Swarm集群

1
2
3
4
5
6
7
8
9
10
11
12
# docker swarm init 初始化一个集群
[root@docker-0 ~]# docker swarm init
Swarm initialized: current node (0onzn4z1ljxw7delulxewvnvk) is now a manager.

To add a worker to this swarm, run the following command:

    docker swarm join --token SWMTKN-1-3vk8ohuxr68hy9o6udjzfi5q8dmasvapcu500tzvs22vpijnny-7qt31z6lamb831ym9qjd23s3y 192.168.3.20:2377

To add a manager to this swarm, run 'docker swarm join-token manager' and follow the instructions.
# 使用下面命令可以生成加入集群的命令
docker swarm join-token manager
docker swarm join-token worker

创建服务

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
[root@docker-0 ~]# docker service --help

Usage:	docker service COMMAND

Manage services

Commands:
  create      Create a new service
  inspect     Display detailed information on one or more services
  logs        Fetch the logs of a service or task
  ls          List services
  ps          List the tasks of one or more services
  rm          Remove one or more services
  rollback    Revert changes to a service's configuration
  scale       Scale one or multiple replicated services
  update      Update a service

Run 'docker service COMMAND --help' for more information on a command.

概念总结

swarm

集群的管理和编号，docker可以初始化一个集群，其他节点可以加入

Node

就是一个docker节点，多个节点就组成了一个网络集群(管理者，工作者)

Service

任务，可以在管理节点或工作节点来运行，

Task
